| Product Attribute | Attribute Value |
|---|---|
| Air Flow | 108 CFM (3058 L/Min.) |
| Approximate Thickness | 1.5 In. (38 mm) |
| Bearing Type | Ball |
| Configuration | Square |
| Current Rating | 0.31 A |
| Dimensions | 4.7 x 4.7 x 1.5 In. (120 x 120 x 38 mm) |
| Fan Type | DC |
| Material | Plastic |
| Maximum Operating Temperature | 70 C |
| Minimum Operating Temperature | -10 C |
| Noise Level | 43 dBA |
| Power Rating | 7.44 W |
| Primary Type | Fan |
| Rotation | CCW |
| Series | |
| Size | 4.7 x 1.5 (120 x 38) In. (mm) |
| Size, Approximate | 4.7 x 4.7 In. (120 x 120 mm) |
| Speed | 2950 RPM |
| Temperature Range | -10 to 70 C |
| Termination | Wire Leads |
| Type | Square |
| Voltage Rating | 24 VDC |
| Weight | 9.2 Oz. |
Overview
Locked rotor output and tachometer options are available on DC wire lead fans by special order, 500-piece minimum. Please contact your local Allied sales representative.
Features:
- Improved Performance
- High Efficiency
- Auto Restart
- Low Input Power
- Lower Operating Voltages
- Longer Life
- Higher Temperature Extremes
- Lower Noise Over Time
- Maximum Shock and Vibration Resistance
